KTM 400
Horizontal Machining Center ( HMC ) · New
- Brand
- KTM
- Model
- 400
- Machine type
- Horizontal Machining Center ( HMC )
- Condition
- New
- Location
- Unknown
- Reference
- ZPM-109867
Technical Specifications
- Pallet Size
- 600 mm
- X Travel
- 550 mm
Description
• Horizontal Machining Center (HMC) Series. • Available models: HMC 400, HMC 630, HMC 800. • Features Automatic Pallet Changer. • Pallet Sizes: 400x400mm, 600x600mm, 800x800mm. • Max. Workpiece Size (HMC 400): Ø 600 x 550mm. • X-Axis Stroke: Up to 1200mm. • Y-Axis Stroke: Up to 900mm. • Z-Axis Stroke: Up to 900mm. • Spindle taper: BT-40 or BT-50. • Spindle Motor Power: Up to 18.5 kW. • Spindle Torque: Up to 107 N-m. • Speed Range: 6000 rpm. • ATC: 24 tools. • Positioning Accuracy: 0.01mm. • Repeatability: 0.008mm. • Weight: Up to 16000 kg. • Optional features: Chip Conveyor, Through Coolant, Spindle Oil Chiller, Probing System. • Standard features: Bed Construction, Extra Wide Design, Ball Screw with C3 Grade, Roller Type LM Guideways, High Speed Rigid Spindle, Smart Tool Management System, Stainless Steel Telescopic Covers, Powder Coated Electric Panel with Air Conditioner, High Pressure Coolant Unit, Auto Lubrication Unit.
